Automatic Gauge Control
Closed-loop thickness control for stable gauge during reversing cold rolling.
20-high cluster mill
20-High Sendzimir Cold Rolling Mill
Engineered for ultra-thin stainless steel strip, precision gauge tolerance, flatness control and stable high-speed cold rolling.
Strip width 350-1780 mm
Rolling speed 800 m/min
Gauge accuracy 5 micron
Tension range 0-50000 N
Application
Built for thin gauge stainless steel and hard material precision rolling.
The 20-high Sendzimir configuration uses a compact cluster roll arrangement to support small-diameter work rolls. This helps the mill deliver high reduction, tight gauge tolerance and responsive flatness control on demanding strip materials.
JINYE configures the stand, hydraulic adjustment, drive, AGC, AFC automatic flatness control, strip tension control and automation system around each customer's strip grade, entry thickness, target gauge, width, coil weight and plant conditions.
Material 200/300/400 series stainless steel and silicon steel
Yield strength up to 800 MPa
Entry thickness 0.8-4.0 mm
Maximum coil weight 28 ton
Control platform Siemens PLC with AGC integration
Control package
Designed around automatic gauge control and strip flatness.
Flatness Control
Strip shape correction through roll system design, tension stability and process tuning.
Process Integration
Pickling, cleaning, tension leveling and slitting equipment can be matched to the rolling process.
Technical parameters
20-high rolling mill specification range.
| Category | Parameter | Value | Unit |
|---|---|---|---|
| Basic | Model reference | 1450 | - |
| Basic | Maximum strip width | 350-1780 | mm |
| Basic | Minimum finished thickness | 0.03 | mm |
| Basic | Maximum entry thickness | 0.8-4.0 | mm |
| Basic | Maximum coil weight | 28 | ton |
| Basic | Material range | 200/300/400 series stainless steel and silicon steel | - |
| Performance | Maximum rolling speed | 800 | m/min |
| Performance | Gauge control accuracy | 5 | micron |
| Performance | Width control accuracy | 0.1 | mm |
| Performance | Flatness control | 10 | I-Unit |
| Performance | Rolling force | 1200 | kN |
| Structure | Roll arrangement | 20-high cluster structure | - |
| Structure | Work roll diameter | 63 | mm |
| Control | Automatic Gauge Control | Closed-loop AGC | - |
| Control | AFC flatness control | Automatic flatness control | - |
| Control | Strip tension control | Automatic stable tension | - |
| Installation | Floor area | 400 | m2 |
| Installation | Total weight | 380 | ton |
| Installation | Installation cycle | 300 | days |
| Operation | Operators | 3 | people |
| Operation | Noise level | 60 | dB |
Custom engineering
Need a mill sized to your strip grade and plant layout?
Share your material, gauge schedule, coil data, speed target, automation requirements and workshop constraints.
